2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS1286426 series
Resolution: 128x64
Voltage: 5V
Display colour: Yellow
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm
Interface: Parallel/SPI/I2C2021-02-22 -
1.54inch 128x64 OLED Display Module
HGS1286437 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-22 -
1.54inch 128x64 Smart Serial OLED Display Module
HGSC128647
Resolution: 128x64
Voltage: 3.3V
Interface: UART
Display colour: Yellow
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 47.0x42.0mm
Viewing area: 37.0x19.5mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128321 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: UART/SPI/USB
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x29.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128322 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: RS232
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x32.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20
-
-
-
2.4inch 128x64 OLED Display Module
HGS1286421V1 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286425 series
Resolution: 128x64
Voltage: 3.3V
Interface: SPI
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286435 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286436 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 Smart Serial OLED Display Module
HGSC128642 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23
-
-
-
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286416 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286445 series
Resolution: 128x64
Voltage: 3.3V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286446 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1309 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286451 series
Resolution: 128x64
Voltage: 3.3V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286449 series
Resolution: 128x64
Voltage: 5V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128643 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128645 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 90.0x47.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23
-
-
-
3.37inch 240x128 OLED Display Module
HGS2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.30mm
Display colour: Yellow/Green2021-02-22 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
3.12inch 256x64 OLED Display Module
HGS256641 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 OLED Display Module
HGS256642 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64OLED Display Module
HGS256646 series
Resolution: 256x64
Voltage: 5V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 Smart Serial OLED Display Module
HGSC256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.8x21.2mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
4.7inch 256x128 OLED Display Module
HGS2561281 series
Resolution: 256x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.01mm
Display colour: Green2021-02-20 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561287 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Interface: CAN/RS485
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
5.5inch 256x64 OLED Display Module
HGS256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Display colour:Green
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm2021-02-22 -
5.5inch 256x64 Smart Serial OLED Display Module
HGSC256644 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
- All
- 0.96 inch
- 1.54 inch
- 2.23 inch
- 2.26 inch
- 2.42 inch
- 2.7 inch
- 2.93 inch
- 3.12 inch
- 3.4 inch
- 4.7 inch
- 5.5 inch
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS1286426 series
Resolution: 128x64
Voltage: 5V
Display colour: Yellow
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm
Interface: Parallel/SPI/I2C2021-02-22 -
1.54inch 128x64 OLED Display Module
HGS1286437 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-22 -
1.54inch 128x64 Smart Serial OLED Display Module
HGSC128647
Resolution: 128x64
Voltage: 3.3V
Interface: UART
Display colour: Yellow
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 47.0x42.0mm
Viewing area: 37.0x19.5mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128321 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: UART/SPI/USB
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x29.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128322 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: RS232
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x32.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23
-
-
-
2.4inch 128x64 OLED Display Module
HGS1286421V1 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286425 series
Resolution: 128x64
Voltage: 3.3V
Interface: SPI
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286435 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286436 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 Smart Serial OLED Display Module
HGSC128642 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286416 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286445 series
Resolution: 128x64
Voltage: 3.3V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286446 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1309 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286451 series
Resolution: 128x64
Voltage: 3.3V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286449 series
Resolution: 128x64
Voltage: 5V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128643 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128645 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 90.0x47.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20
-
-
-
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23
-
-
-
3.12inch 256x64 OLED Display Module
HGS256641 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 OLED Display Module
HGS256642 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64OLED Display Module
HGS256646 series
Resolution: 256x64
Voltage: 5V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 Smart Serial OLED Display Module
HGSC256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.8x21.2mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
3.37inch 240x128 OLED Display Module
HGS2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.30mm
Display colour: Yellow/Green2021-02-22 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
4.7inch 256x128 OLED Display Module
HGS2561281 series
Resolution: 256x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.01mm
Display colour: Green2021-02-20 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561287 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Interface: CAN/RS485
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
5.5inch 256x64 OLED Display Module
HGS256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Display colour:Green
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm2021-02-22 -
5.5inch 256x64 Smart Serial OLED Display Module
HGSC256644 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128321 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: UART/SPI/USB
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x29.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128322 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: RS232
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x32.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20
-
-
-
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286416 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286421V1 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286425 series
Resolution: 128x64
Voltage: 3.3V
Interface: SPI
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-22 -
1.54inch 128x64 OLED Display Module
HGS1286426 series
Resolution: 128x64
Voltage: 5V
Display colour: Yellow
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm
Interface: Parallel/SPI/I2C2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286435 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286436 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22
-
-
-
3.12inch 256x64 OLED Display Module
HGS256641 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 OLED Display Module
HGS256642 series
Resolution: 256x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
5.5inch 256x64 OLED Display Module
HGS256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Display colour:Green
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm2021-02-22 -
3.12inch 256x64OLED Display Module
HGS256646 series
Resolution: 256x64
Voltage: 5V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.78x21.18mm
Display colour: Yellow/Green/White/Blue2021-02-22 -
3.12inch 256x64 Smart Serial OLED Display Module
HGSC256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.8x21.2mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
5.5inch 256x64 Smart Serial OLED Display Module
HGSC256644 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
3.37inch 240x128 OLED Display Module
HGS2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.30mm
Display colour: Yellow/Green2021-02-22 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
4.7inch 256x128 OLED Display Module
HGS2561281 series
Resolution: 256x128
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1322 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.01mm
Display colour: Green2021-02-20 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561287 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Interface: CAN/RS485
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23
-
-
-
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23
-
-
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286416 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286421V1 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS1286426 series
Resolution: 128x64
Voltage: 5V
Display colour: Yellow
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm
Interface: Parallel/SPI/I2C2021-02-22
-
-
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
-
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128322 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: RS232
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x32.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.4inch 128x64 Smart Serial OLED Display Module
HGSC128642 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128643 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128645 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 90.0x47.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20 -
3.12inch 256x64 Smart Serial OLED Display Module
HGSC256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.8x21.2mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
5.5inch 256x64 Smart Serial OLED Display Module
HGSC256644 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128321 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: UART/SPI/USB
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x29.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.4inch 128x64 Smart Serial OLED Display Module
HGSC128642 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128643 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
2.7inch 128x64 Smart Serial OLED Display Module
HGSC128645 series
Resolution: 128x64
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 90.0x47.0mm
Viewing area: 65.0x33.0mm
Interface: UART/SPI/RS232
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20 -
1.54inch 128x64 Smart Serial OLED Display Module
HGSC128647
Resolution: 128x64
Voltage: 3.3V
Interface: UART
Display colour: Yellow
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 47.0x42.0mm
Viewing area: 37.0x19.5mm
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-20 -
0.96inch 128x64 Smart Serial OLED Display Module
HGSC1286411
Resolution: 128x64
Voltage: 5V
Size: 0.96"
Interface: UART
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 33.0x29.0mm
Viewing area: 23.74x13.20mm
Display colour:Blue/Blue-Yellow
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
3.12inch 256x64 Smart Serial OLED Display Module
HGSC256643 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 80 ℃
Outline dimension: 105.6x31.8mm
Viewing area: 78.8x21.2mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
5.5inch 256x64 Smart Serial OLED Display Module
HGSC256644 series
Resolution: 256x64
Voltage: 5V/3.3V
Interface: UART/SPI/RS232
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 163.5x54.0mm
Viewing area: 137.6x35.7mm
Display colour: Yellow/Green/White/Blue
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286416 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-23
-
-
-
2.23inch 128x32 Smart Serial OLED Display Module
HGSC128321 series
Resolution: 128x32
Voltage: 5V/3.3V
Interface: UART/SPI/USB
Display colour: Yellow/Green/Blue
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x29.0mm
Viewing area: 57.0x15.1mm
Suitable for 1U chassis
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries.2021-02-20 -
3.37inch 240x128 Smart Serial OLED Display Module
HGSC2401281 series
Resolution: 240x128
Voltage: 5V/3.3V
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 108.0x74.8mm
Viewing area: 77.58x42.3mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x128 Smart Serial OLED Display Module
HGSC2561283 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 144.0x104.0mm
Viewing area: 109.2x58.0mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19 -
4.7inch 256x64 Smart Serial OLED Display Module
HGSC2561285 series
Resolution: 256x128
Voltage: 5V/3.3V
Display colour: Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 148.0x79.8mm
Viewing area: 109.2x58.01mm
Interface: UART/SPI/RS232/USB
Built-in GBK code, including Chinese, Japanese, Korean and other font libraries2021-02-19
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.4inch 128x64 OLED Display Module
HGS1286421V1 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 61.8x50.0mm
Viewing area: 57.5x30.0mm
Display colour: Yellow/Green2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS1286426 series
Resolution: 128x64
Voltage: 5V
Display colour: Yellow
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm
Interface: Parallel/SPI/I2C2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286435 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
2.4inch 128x64 OLED Display Module
HGS1286436 series
Resolution: 128x64
Voltage: 5V/3.3V
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 57.5x30.0mm
Interface: Parallel/SPI/I2C
Display colour: Yellow/Green2021-02-22 -
1.54inch 128x64 OLED Display Module
HGS1286437 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-22 -
2.7inch 128x64 OLED Display Module
HGS1286445 series
Resolution: 128x64
Voltage: 3.3V
Built-in SSD1309 controller
Interface: Parallel/SPI/I2C
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 75.0x56.5mm
Viewing area: 65.0x33.0mm
Display colour: Yellow/Green2021-02-22
-
-
-
2.26inch 16x2 character OLED Display Module
HCS1625 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel/SPI/I2C
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.26inch 16x2 character OLED Display Module
HCS1626 series
Resolution: 16 characters x 2 lines
Voltage: 5V/3.3V
Interface: Parallel
Display colour: Yellow/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 80.0x36.0mm
Viewing area: 58.22x13.52mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2022 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in US2066 controller
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.93inch 20x2 character OLED Display Module
HCS2025 series
Resolution: 20 characters x 2 lines
Voltage: 5V/3.3V
Display colour: Yellow/Green/White
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 116.0x37.0mm
Viewing area: 75.5x13.5mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS128321 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x35.0mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.23inch 128x32 OLED Display Module
HGS12832 series
Resolution: 128x32
Voltage: 3.3V
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Display colour: Yellow/Green/Blue
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 66.5x31.45mm
Viewing area: 57.0x15.1mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128641 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 85.0x58.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128645 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128646 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 93.0x70.0mm
Viewing area: 65.0x33.0mm2021-02-23 -
1.54inch 128x64 OLED Display Module
HGS128647 series
Resolution: 128x64
Voltage: 3.3V
Display colour: Yellow
Interface: Parallel/SPI/I2C
Built-in SSD1305 controller
Operating temperature:-40 ℃~ 70 ℃
Outline dimension: 54.0x39.5mm
Viewing area: 37.0x19.5mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS128649 series
Resolution: 128x64
Voltage: 3.3V
Interface: Parallel/SPI
Display colour: Yellow/Green
Built-in SSD1325 controller
Operating temperature:-30 ℃~ 70 ℃
Outline dimension: 75.0x53.5mm
Viewing area: 65.0x33.0mm2021-02-23 -
2.7inch 128x64 OLED Display Module
HGS1286413 series
Resolution: 128x64
Voltage: 5V/3.3V
Interface: Parallel/SPI
Built-in SSD1325 controller
Display colour: Yellow/Green
Operating temperature:-40 ℃~ 80 ℃
Outline dimension: 89.5x45.5mm
Viewing area: 65.0x33.0mm2021-02-23
-
-
PRODUCTS
Low Temperature OLED Module
- The operating temperature of OLED module can reach -40℃ or even lower after the materials of an OLED are processed. While working at -40℃,it can remain excellent contrast and response speed.Low temperature OLED module is the first choice for displays in cold areas. A variety of low temperature OLED modules developed by Tsingtek have similar appearances and structures to ordinary LCD modules, which are simple to use and easy to install.
Product Screening
PRODUCTS
